Electro magnetic lock with signal return 180 kg
Electro magnetic lock with signal return 180 kg
REF: LK101
Specifications
- Electromagnetic lock with simple opening and return signal that allows new actions to be configured after opening the door.
- Holding force: 180 kg.
- Working mode: NC, the door opens when there is no power.
- Closure body size (L x W x H): 140 x 10 x 32 mm.
- Retaining plate size (L x W x H): 170 x 20 x 40 mm.
Watch video
PVP
€27.57
€13.79
Price including VAT:
€13.79
PVD
€24.13
PVP: Retail price.
Check conditions.
PVP: Sale price to distributors.
Check conditions.
Buy before:
Receive it:
Thursday 28
Delivery times are approximate. Cablematic is not responsible for delays.
2 yearswarranty
14 daysreturns
100%safe
Specifications
- Electromagnetic lock with simple opening and return signal that allows new actions to be configured after opening the door.
- Holding force: 180 kg.
- Working mode: NC, the door opens when there is no power.
- Closure body size (L x W x H): 140 x 10 x 32 mm.
- Retaining plate size (L x W x H): 170 x 20 x 40 mm.
Related products
Keywords
Did not find what you were looking for? These topic could help you
Purchased together regularly
More info
Security locking system for metal, wooden or glass doors. The lock remains activated as long as there is voltage in the circuit. The electromagnet block can be installed on the door frame or canopy, so that when active it generates an electromagnetic field that strongly attracts the metal plate installed on the door. Control of the lock can be done using a push button, remote control, control panel, etc. Compact and resistant design. No noise during operation. Includes hex wrench and hardware for installation.
Specifications
Specifications
- Electromagnetic lock with simple opening and return signal that allows new actions to be configured after opening the door.
- Holding force: 180 kg.
- Working mode: NC, the door opens when there is no power.
- Closure body size (L x W x H): 140 x 10 x 32 mm.
- Retaining plate size (L x W x H): 170 x 20 x 40 mm.
- Operating voltage: DC12V 0.5 A / 24V 0.25 A.
- Gross Weight: 1.01 kg
- Product size (width x depth x height): 17.0 x 3.5 x 4.0 cm
- Number of packages: 1
- Packages size: 20.7 x 5.6 x 5.5 cm
- Master-pack: 1
Technical terms
- Types of tips for screwdrivers
Types of tips for screwdrivers
Although there are infinity tips as manufacturers or type of use, these are the most commonly tips used in the electronics industry, hardware or electricity.
1. Slot: Characterized by its flat and elongated tip.
2. Phillips: It may be the most used, its tip is shaped like a four-pointed star. Also called commonly screwdriver
3. Pozidriv: Like the previous model, but with a twist. Inside it has 4 slots in a star more.
4. Torx: Widely used in vehicles, its shape is a star with 6 points.
5. Security Torx: Same as above, but inside has a pin.
6. Hex: Point-shaped or hexagon Allen calls. Such tips are distinguished from the rest because they are able to withstand higher torque strength.
1. Slot: Characterized by its flat and elongated tip.
2. Phillips: It may be the most used, its tip is shaped like a four-pointed star. Also called commonly screwdriver
3. Pozidriv: Like the previous model, but with a twist. Inside it has 4 slots in a star more.
4. Torx: Widely used in vehicles, its shape is a star with 6 points.
5. Security Torx: Same as above, but inside has a pin.
6. Hex: Point-shaped or hexagon Allen calls. Such tips are distinguished from the rest because they are able to withstand higher torque strength.
