The lumen (symbol: lm) is the unit of the International System of Units to measure the luminous flux, a measure of the light power emitted by the source. The luminous flux of radiant flux difference that the former provides the variable sensitivity of the eye to different wavelengths of light and the latter involves all electromagnetic radiation emitted by the source according Wien law and Stefan-Boltzmann regardless of whether such radiation is visible or not. 1 lm = 1 cd. sr = 1 lx. m2

In IEC connector or cable with a base (usually plastic) and a plug to connect to the socket (plug), if we put these two things we would get the named SCHUKO is the overall connector. The schuko not determine the type of connector. It would be determined by the specification of the International Electrotechnical Commision (IEC). We leave a small sample of Schukos internationally.

hen we talk about IP code (International Protection) we talk about an international standard (IEC 60529) which classifies the protection against external factors, solid or liquid, that has a component or electronic device; LED strips, controllers, meters, security cameras, etc.

This alpha-numerically standard has been designed to sort different levels of protection. Nomenclature starts with IP followed by two numeric values.

- Example IP68:

The first value ranges from 0 to 6 and indicates the protection against solid agents. In this case, strong protection against dust.

The second value is between 0 and 8 and indicates the protection against liquid agents. In this case the complete and prolonged immersion during the time specified by the manufacturer.

We could say that the larger the number is greater IP protection has a device.

In below table, we can see different IP protections levels available.

IPXX	First digit (IPxx)	Second digit (IPxx)
0	Unprotected.	Unprotected.
1	Protection against objects of> 50 mm diameter.	Protection against vertically dripping water.
2	Protection against objects of> 12.5 mm diameter.	Protection against inclined drip water up to 15°.
3	Protection against objects of> 2 mm in diameter.	Protection against water projected from any direction, up to 60°.
4	Protection against objects of> 1 mm in diameter.	Protection against splashing water any direction.
5	Ingress of dust is not entirely revented, but it must not enter in sufficient quantity to interfere with the satisfactory operation of the equipment .	Protection against water jets.
6	Dust tight.	Protection against strong jets of water.
7		Protection against complete immersion up to 1 meter for 30 minutes.
8		Protection against complete and prolonged immersion.

Within the different types of electrical cables we can find single or multifilament cables. The difference lies in the number of conductors that make up the cable. Single wire cables contain only a single conductive wire, whereas multi-wire cables contain more than one wire. Do not confuse multifile (A) or single wire (B) with monopolar (C), bipolar (D) or multipolar (E) cable. Monopolar cables have only oneSingle conductor, bipolar cables have two conductors, while multi-pole cables have more than two conductors. It may be said that any unipolar, bipolar or multipolar cable can be single-ended or multi-stranded. In the case of single wire cables we will talk about rigid cables, whereas the multifilament cables will be flexible.
In the following table you can see the difference between them.

The degree Kelvin (K) is the unit used to classify the color temperature according to the scale created by William Thomsom from degrees Celsius. Lord Kelvin based on the table of William constructed a scale of temperatures to which its name is attributed to him.
A deeper explanation would introduce us into the world of physics, so in our sector knowing the relationship between Kelvins and kind of light will be sufficient.and.
This measurement factor is useful to know at a glance which tone or quality of light has a certain light source, for example, if we are going to buy a light bulb or a fluorescent we may be interested in knowing the kelvin it provides, as it will depend on This factor whether the light will be yellow or white.
The lower the kelvin value will be the light temperature, for example a 1600K bulb will have a temperatUra and color quality similar to the light of an exit or sunset. While a light bulb with 5000K will be more like daylight.
To better understand the relationship between kelvin and light temperature is attached the following table, where in a visual way it becomes easier to choose the type of bulb that best suits our needs.

A: It is equivalent to the temperature of a candle, it is aIn yellow light.

B: It resembles the color of dawn, it is similar to a tungsten bulb.

C: It is the tone of light of the old bulbs that were not led, filament bulb.

D: Similar to a study light.

E: Similar to mid-afternoon light about 20 °, similar to a fluorescent light warm.

F: Similar to mid-afternoon light at about 30 °.

G: Daylight, similar to a lightOf a flash.

H: Sunlight at noon.

I: Very sunny day and clear sky.

J: Partly cloudy day.

K: Cloudy day.

L: Wide shade clear day.

M: Very cloudy day.

N: Blue sky without sun.

O: Very clear day.

Proximity or range sensors are used in many installations requiring an action according to the distance (D) of an object.
They are also used in robotics to control the movement according to the environment, in motorized or domotic installations, the applications can be many and very different.
There are a variety of proximity sensors, including the most common are position switches, Capacitive sensors, inductive sensors, photoelectric sensors where an emitter (E) and a receiver (R), ultrasonic sensors and magnetic sensors are required.
Each of these sensors have the same function, but each of them uses different systems for the detection, either by contact, sound, etc.
Its detection capacity varies according to the type of sensor, and can vary from millimeters to meters. We can vEr these sensors in automatic floor cleaning systems, safety barriers, rear parking sensors for cars, mobile phones, etc.

VAC would be the abbreviation of Volt Altern Current which would be translated Volts of alternating current. The difference between VDC is that its sinusoidal oscillation achieving a more efficient energy transmission.

The alternating current is the energy that we receive in our homes, it is generated in the power plants by means of alternators.

The intensity of this type of current varies with time, and changes direction 50 times throughsecond (50hz). The generated voltage changes in the form of sine wave so it is not constant.

In the image:

1. Current by pulsations.
2. Direct current (DC).
3. Alternating current (AC).
4. Variable current.
