Rack mount PDU Power Distribution Unit 19" 1U 7 UK BS-1363 Power Strip
REF: RE083
Specifications
  • 7-socket BS-1363 female strip.
  • 230V / 13A. Protection fuse built into the plug.
  • Frequency: 50 Hz.
  • It does not have a switch.
  • 1.6m electric cable type H05VV-F 3Gx1.5mm² and terminated in BS-1363 male.
play_button Watch video
More info
PVP
25.55
Price including VAT: 25.55
PVD
22.56
Shipping costs: 30,75 *
GB-SE1 1ES
Delivery times are approximate. Cablematic is not responsible for delays.
2 years
warranty
14 days
returns
100%
safe

In stock
Available more than 10

More info
Specifications
  • 7-socket BS-1363 female strip.
  • 230V / 13A. Protection fuse built into the plug.
  • Frequency: 50 Hz.
  • It does not have a switch.
  • 1.6m electric cable type H05VV-F 3Gx1.5mm² and terminated in BS-1363 male.

More info

Power strip specially designed to be mounted in a 19 "rack cabinet but can also be used as a standard power strip not installed in a rack cabinet. Structure mounted in a black plastic housing. The strip occupies 1U of height in a rack cabinet and It has two fixed metal tabs. Model to be installed horizontally or vertically in a rack cabinet, since the width coincides with that of the 19 "rack.

specs
  • 7-socket BS-1363 female strip.
  • 230V / 13A. Protection fuse built into the plug.
  • Frequency: 50 Hz.
  • It does not have a switch.
  • 1.6m electric cable type H05VV-F 3Gx1.5mm² and terminated in BS-1363 male.
  • Interconnection of female BS-1363 baseboards by means of a rigid internal busbar.
  • Size: 44 (height) x 487 (length with tabs) x 43 (depth) mm.
  • Central gutter length without flanges: 446 mm.
  • Gross Weight: 870 g
  • Product size (width x depth x height): 48.7 x 4.6 x 4.6 cm
  • Number of packages: 1
  • Packages size: 51.0 x 9.5 x 5.5 cm
  • Master-pack: 25

Videos

play_button Watch video

Technical terms

  • RACK 19
  • Hz
  • Schuko
  • BS-1363
  • Rack unit (U)
  • Electrical cable sections
  • Colors of electric cables
  • Colors insulating tape
  • Types of fuses
RACK 19
A rack is a metal support designed to house electronic, computer and communications equipment. The measures for the width are normalized to be compatible with most equipment manufacturers. They are also called racks, cabinets, cabinets or closets. Each column has holes at regular intervals called U rack units (Pictured: 4) grouped in threes. The height (Pictured:5) of the racks is standardized and external dimensions of 200 mm by 200 mm. Being normal that from 4U to 46/47U height width types (Pictured: 7). Standard 600 mm or 800 mm Types of background (Pictured: 6) The depth of the frame is not standardized, as this flexibility is granted (Pictured: 8) to the equipment. The most common are: - 450 mm - 600 mm - 800 mm - 900 mm - 1000 mm - 1200 mm Type 19-inch rack can find various types of 19-inch rack. Rack Mural (Pictured: 2): Used to accommodate electronic network. They are the smallest and are anchored to wall. Rack Pie (Pictured: 1): They are used primarily for servers, UPS and network electronics. Open Rack (Pictured: 3): Open Rack Racks are available only modelsstructure, eliminating doors and other accessories.
