pH meter PCE-PH20M
pH meter PCE-PH20M
REF: PC424
Specifications
- easy handling.
- Robust penetration electrode.
- recalibratable.
- Waterproof (IP67).
- Ideal for food quality control.
PVP
€394.88
Price including VAT:
€394.88
PVD
€367.65
PVP: Retail price.
Check conditions.
PVP: Sale price to distributors.
Check conditions.
2 yearswarranty
14 daysreturns
100%safe
We will notify you when it is back in stock.
Specifications
- easy handling.
- Robust penetration electrode.
- recalibratable.
- Waterproof (IP67).
- Ideal for food quality control.
Related products
More info
The ph meter is an easy-to-use and high-precision device, specially designed to measure the pH value of solid, liquid and semi-solid foods. The robust penetration electrode and the waterproof housing (IP67) allow you to use the device in harsh conditions. The device has the HOLD function to freeze the pH value on the screen, as well as the automatic disconnection function to save energy. It is recommended to clean the electrode with distilled water after each use. Manufactured by PCE with reference PCE-PH20M.
Specifications
Specifications
- easy handling.
- Robust penetration electrode.
- recalibratable.
- Waterproof (IP67).
- Ideal for food quality control.
- Suitable for measuring liquids, gels, semi-solid foods, such as jam, meat or cheese.
- Measurement range from 0 to 14 pH.
- Temperature range between 0 and 60 ºC.
- Ambient humidity up to 80% RH
- Automatic shutdown function to extend battery life.
- Can be calibrated later to guarantee high precision.
- It is recommended to periodically recalibrate the device or when the pH electrode is replaced.
- Storage solution to ensure accurate measurements over a long period of time.
- Pepsin/hydrochloric acid cleaning solution for cleaning the penetrating pH-meter.
- Annual recalibration.
- Gross Weight: 400 g
- Number of packages: 1
- Master-pack: 1
Technical terms
- IP Protection
IP Protection
hen we talk about IP code (International Protection) we talk about an international standard (IEC 60529) which classifies the protection against external factors, solid or liquid, that has a component or electronic device; LED strips, controllers, meters, security cameras, etc.
This alpha-numerically standard has been designed to sort different levels of protection. Nomenclature starts with IP followed by two numeric values.
- Example IP68:
The first value ranges from 0 to 6 and indicates the protection against solid agents. In this case, strong protection against dust.
The second value is between 0 and 8 and indicates the protection against liquid agents. In this case the complete and prolonged immersion during the time specified by the manufacturer.
We could say that the larger the number is greater IP protection has a device.
In below table, we can see different IP protections levels available.
This alpha-numerically standard has been designed to sort different levels of protection. Nomenclature starts with IP followed by two numeric values.
- Example IP68:
The first value ranges from 0 to 6 and indicates the protection against solid agents. In this case, strong protection against dust.
The second value is between 0 and 8 and indicates the protection against liquid agents. In this case the complete and prolonged immersion during the time specified by the manufacturer.
We could say that the larger the number is greater IP protection has a device.
In below table, we can see different IP protections levels available.
| IPXX | First digit (IPxx) | Second digit (IPxx) |
| 0 | Unprotected. | Unprotected. |
| 1 | Protection against objects of> 50 mm diameter. | Protection against vertically dripping water. |
| 2 | Protection against objects of> 12.5 mm diameter. | Protection against inclined drip water up to 15°. |
| 3 | Protection against objects of> 2 mm in diameter. | Protection against water projected from any direction, up to 60°. |
| 4 | Protection against objects of> 1 mm in diameter. | Protection against splashing water any direction. |
| 5 | Ingress of dust is not entirely revented, but it must not enter in sufficient quantity to interfere with the satisfactory operation of the equipment . | Protection against water jets. |
| 6 | Dust tight. | Protection against strong jets of water. |
| 7 | Protection against complete immersion up to 1 meter for 30 minutes. | |
| 8 | Protection against complete and prolonged immersion. |
